562400-000, Issue 1.3 January 2022
Page 14 of 61
6. Top Menu
The Top Menu screen allows access to all the system functions:
Limits menu
Lifting menu
Tool selection / System Type (Optional)
Test Diagnostics
If the icons are hidden, press any button to reveal. To return to the Top Menu from a sub menu
press the “Hide Icons”/EXIT button until the Top Menu is displayed.
To hide the icons when at the Top Menu, press the “Hide
icons” button once more.
6.1. Tool Selection Menu (Optional)
The system can monitor the position of a tool or multiple tools. If more than one
tool has been calibrated, they must be manually selected via the example Select
Tool selection screen shown below. Use the Arrow icon buttons to select the
required tool and confirm using the Tick icon button.
Tool selection
Menu level indicator
selection
Hide icons
Test Diagnostics
Accept highlighted
Tool
Moves highlighter
DOWN
Moves highlighter UP
Exit without change
To Next Page
