562400-000, Issue 1.3 January 2022
Page 44 of 61
7.1. Limit Control Override
7.1.1. Soft Override
After three seconds a soft override icon may appear in the right hand middle icon if any
type of limit has been reached (Angular slew limit shown). If soft override is utilised, the
machine hydraulics will be re-enabled. However, the internal alarm will stay active, the
red LED will flash, the beacon (if fitted) will switch off and an In Override message will
appear on the display. Once the alarm condition has been corrected i.e. The machine
has returned to a safe position, the system will automatically clear the override state
and revert to normal operation.
7.1.2. Master Override key Switch
The system can optionally be fitted with a key operated Master Override switch.
See section 4.1 for further details.
Once the limits are set, the internal alarm will sound and the RED LED
will light if the equipment reaches the current limit. Always check that
the limit activates at the set point. The restriction cannot be deactivated
if in the alarm state. Do not travel once a slew limit has been set.
Observe the operational limitations given in section
Soft override
