562400-000, Issue 1.3 January 2022
Page 46 of 61
8.2. On Screen Component Error Messages
PME continuously monitors the presence and condition of the safety controller and sensors. If the safety
controller or any sensor fails, an error will appear at the bottom of the display, the cab mounted beacon (if
fitted) will indicate that the system is NOT active, the display red LED will flash and the internal and
external alarms will sound.
If any of these messages appear, please seek a repair from your local Prolec service engineer. Please
report the ID number displayed to the service engineer, as they will need it to correctly identify and rectify
the fault.
Sensor Broadcast Error ID 33 Boom Piston / Rod Pressure Sensor Error
Sensor Broadcast Error ID 32 Boom AS7 Angle Sensor Error
Sensor Broadcast Error ID 96 Artic AS7 Angle Sensor Error
Sensor Broadcast Error ID 64 Arm AS7 Angle Sensor Error
Sensor Broadcast Error ID 128 Hitch AS7 Angle Sensor Error
Sensor Broadcast Error ID 224 Cant AS7 Angle Sensor Error
Sensor Broadcast Error ID 352 X4 Analogue interface, AS10 & Boom/Artic/Arm/Reeling drum
Sensor Broadcast Error ID 192 Slew Angle Sensor Error
Sensor Broadcast Error ID 43XX Safety Controller / I/O module 43XX (X denotes box ID)
Output Failure X - X
Output Failure on Safety Controller / I/O module X Output X (X
denotes box ID and Input Number)
Unknown Duty Incorrect Input Configuration/ slew position
Input Failure X - X
Input Failure on Safety Controller / I/O module X Output X(X
denotes box ID and Input Number)
Override Keyswitch Failure Override Key switch has been Damaged/Disconnected
Override Timed out
Override feature has been enabled for X minutes (Default 30
minutes) and has been reset
Tamper Detected
Beacon, Alarm, Override Key switch, Output/ Input
Disconnected
