562400-000, Issue 1.3 January 2022
Page 34 of 61
7.5.1. Angular Slew Limit Setting - using Current Slew Angle
Select angular slew limiting, follow the on screen instructions.
Do not travel once a slew limit has been set.
Step One
Extend equipment to appropriate
position.
Step two
Move to the left slew limit, press any
button to set the left limit. A marker will
be placed to indicate its position.
Continued on next page
Step by step instructional banner
Press this button to start
the setup procedure
Set to angular slew
To Next Page
