562400-000, Issue 1.3 January 2022
Page 35 of 61
Once limits are set, the internal alarm will sound and the RED LED will
light if the equipment reaches either limit. Always check that the current
limit activates at the set points. The restriction cannot be deactivated if
in the alarm state. Do not travel once a slew limit has been set. Observe
the operational limitations given in section
4
.
Step three
Move to right slew limit, press any button
to set the right slew limit. Another
marker will be placed here.
Left slew restriction marker
Step four
Move to safe zone and press any button
to complete operation.
Left and right slew markers with
safe zone between the two
The hatched hazard zone will be
shown on the main screen.
Check the limits are working as
required.
Safe Directional Indicators. The left and
right arrows indicate if it is safe GREEN, or
unsafe RED to slew in that direction.
PME 405 only: AMBER arrows indicate
that motion is slowed in that direction
