562400-000, Issue 1.3 January 2022
Page 9 of 61
5. Operating Instructions
5.1. Power Up
The PME system automatically powers up when
the machine ignition is switched on. The in-cab
display incorporates a 4.3” high resolution LCD
display and is controlled with three buttons at
each side. Three status LEDs and an internal
alarm provide further information. The display is
secured to the machine using a flexible ball
mounting allowing easy adjustment for personal
viewing preference.
1. On starting up, the system will perform a self test. All LEDs will flash; the internal display
alarm and the external alarm (if fitted) will sound momentarily.
2. The operator will be asked to review the system’s safety features.
(Note: older system types may not display this screen – skip to step 4 if it does not appear)
Individual safety features may be disabled or re-enabled, if appropriate for the current job
and work site. For example, if the work site has no overhead hazards, the operator may
disable the height limiter function.
Each safety feature is initially set/enabled as it was set before the last power-down.
The operator is responsible for verifying that the safety features are enabled
appropriately for the job/work site.
If the height or slew limiter functions are enabled, the operator is responsible for
checking that the movement limits are correctly configured:
See section 7.1 for configuring Height Limits
See section 7.5 for configuring Slew Limits
