Accuracy
Terrestrial bands ±1.5 dB (30-120 dBµV, 45-865 MHz) (22 °C±5 °C)
Satellite band ±2.5 dB (40-100 dBµV, 950-2050 MHz) (22 °C ± 5 °C)
Overrange indication ↑, ↓
MEASUREMENTS MODE
Terrestrial bands
Analogue channels Level, Video-Audio ratio and Carrier-Noise ratio.
Digital channels Channel power, Carrier-Noise ratio and Channel
identification.
Satellite band
Analogue channels Level and Carrier-Noise ratio.
Digital channels Channel power and Carrier-Noise ratio.
DATALOGGER function
3
Measurements automatic acquisition and storage.
Analogue channels Level, C/N and V/A ratios.
Digital channels Frequency offset, MPEG-2 detection, power, C/N,
MER, CBER, VBER and noise margin.
SAT IF TEST Function
4
IF distribution network response for satellite band.
ATTENUATION TEST Function
5
Signal distribution network response for terrestrial
band.
SPECTRUM ANALYSER MODE
Satellite band 30 dBµV to 120 dBµV (31.6 µV to 1 V)
Terrestrial bands 10 dBµV to 120 dBµV (3.16 µV to 1 V)
Measurement bandwidth
Terrestrial 230 kHz
Satellite 4 MHz
Span
Terrestrial Full span (full band) - 500 - 200 - 100 - 50 - 32 - 16
- 8 MHz selectable.
Satellite Full span (full band) - 500 - 200 - 100 - 50 - 32 - 16
MHz selectable.
Markers 1 with Frequency and level indications.
Measurements
Terrestrial bands
Analogue channels Level.
Digital channels Channel power.
Satellite band
Analogue channels Level.
Digital channels Channel power.
3
Using PkTools software application with a PC.
4
Function to be used with RP-250 or RP-050 IF signal simulator.
5
Function to be used with RP-250 or RP-080 pilot signals simulator.
