USER’S MANUAL. PRODIG-5
11/2006 Page 7
English
MONITOR DISPLAY
Monitor TFT colour 5 inches.
Colour system PAL, SECAM and NTSC
TV standard M, N, B, G, I, D, K and L
Spectrum mode Variable span, dynamic range and reference level
by means of arrow cursors.
Sensibility 40 dBµV for correct synchronism.
BASE BAND SIGNAL
VIDEO
External video input Scart.
Sensibility 1 Vpp (75 Ω) positive video
Video output Scart (75 Ω)
SOUND
Input Scart
Outputs Built in speaker, Scart.
Demodulation TV PAL, SECAM, NTSC system according to DVB-
T, DVB-C, DVB-S and MPEG standards.
De-emphasis 50 µs
Subcarrier Digital frequency synthesis according to the TV
standard.
RS-232C INTERFACE For service and calibration.
EXTERNAL UNITS POWER
SUPPLY Through the RF input connector.
Terrestrial and Satellite External or 5/13/15/18/24 V
22 kHz signal Selectable in satellite band.
Voltage 0.6 V ± 0.2 V
Frequency 22 kHz ± 4 kHz
Maximum power 5 W
DiSEqC
6
GENERATOR According to DiSEqC 1.2 standard.
POWER SUPPLY
Internal
Batteries 7.2 V 11 Ah Li-Ion battery.
Autonomy > 3.5 hours in continuous mode.
Recharging time 3 hours up to 80% (instrument off)
External
Voltage 12 V
Consumption 35 W
6
DiSEqC
TM
is a trademark of EUTELSAT.
