USER’S MANUAL. PRODIG-5
Page 16 11/2006
STEP 3.- To carry out a complete channel band exploration
1. Select the frequency band to explore [14] (terrestrial or satellite).
2. Activate the exploration process by holding
[25] key pressed.
3. Press [10] key to visualise the channels detected and [6] to change
between channels from detected channels list.
STEP 4.- To carry out the tuned channel identification
1. Select the frequency band to explore
[14] (terrestrial or satellite).
2. Activate the identification process pressing once on [25] key.
3. Press [10] key to visualise the signal detected from channel or frequency
identified or
[13] to monitor the corresponding spectrum.
NOTE: In the case that is desired to explore or identify DVB-C signals it is necessary
to select previously DVB-C standard as digital signal identifier through
[22] PREFERENCES menu.
STEP 5.- Making measurements
1. Select the channel or frequency [24] to measure by means of the rotary selector
[1].
2. Press [12] key to select the type of measurement until on screen appears the
corresponding measurement.
