ProMinent gamma/ X Supplementary Operating Instructions

2.7.1.2 Manufacturer specific profile area 0x2000-0x5FFF
Index S Name Type Description Objects Attr
2A00h 0 DP_output_cont (set‐
point)
U16 Frequency in %
(0=100.0%)
RPDO1 wr
2A01h 0 DP_output_actual U16 Frequency in %
(0=100.0%)
TPDO1 ro
2A02h 0 DP_batch_time_stam
p
U16 Time stamp last
received com‐
mand
RPDO2 wo
2A03h 0 DP_batch_value U16 Batch factor RPDO2 wo
2A04h 0 DP_stroke_len U8 Stroke length TPDO1 rO
2A05h 0 DP_level U8 Liquid level
metering container
TPDO2 rO
2A10h 0 DP_state U16 0=out of ctrl,
1=mem, 2=cal,
3=pos/neg
4=prime,
5=warning,
6=errors, 7=stops,
8-11=mode,
12=aux;13=flow;1
4=pause,15=hand/
bus
TPDO1 ro
2A11h 0 DP_Control U8 1= batch-mem,
2=setp. pos/neg,
3=calibrated,
4=flowctrl active,
6=reset
SDO rw
2A12h 0 DP_Mode U8 0=stop,1=manual,
2=batch,
SDO wo
2A20h 0 DP_stroke_max U16 max. stroke rate
(strokes/min)
SDO ro
2A21h 0 DP_metering volume Float in 1/stroke (at
100% stroke)
SDO wr
2A22h 0 DP_measuring_unit U8 0=litre, 1=gallon SDO wr
2A30h 0 DP_volume U32 in ml since last
reset
SDO ro
2A31h 0 DP_stroke_cnt U16 strokes since last
reset
SDO ro
2A33h 0 DP_rem_stroke U16 Remaining stroke
no. (in batch
mode)
SDO ro
2A35h 0
PCO_HighestSubIn
dex
U8 ro
1 FlowControl U8 Bit SDO wo
2 BatchMem U8 Bit SDO wo
3 ClearCount U8 Bit SDO wo
3FBBh 0
PCO_HighestSubIn
dex
U8
1 U32 Identity code RO
Supplementary Operating Instructions CANopen
21

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
