ProMinent gamma/ X Supplementary Operating Instructions

Index S Name Type Description
Max
Objects Attr
5106h 1 Dosiermen‐
genzähler
Float Metering
volume
counter
SDO RO
5107h 1 Calibration
strokes:
U32 Calibration
strokes
SDO RO
5108h 1 Rest-Dosier‐
menge
Float Remaining
metering
quantity
SDO RO
5109h 1 Ist-Hublänge Float Current
stroke length
SDO RO
510Ah 1 Soll-
Hublaenge
Float Setpoint
stroke length
SDO RW
510Bh 1 Soll-Hubfre‐
quenz
U16 Setpoint
stroke rate
SDO RW
510Ch 1 Ist-Hubfre‐
quenz
U16 Current
stroke rate
SDO RO
510Dh 1 Dosiervo‐
lumen pro
Auslösung
Float Metering vol‐
umes per
release
SDO RW
510Eh 1 Ist-Dosierleis‐
tung
Float Current
metering
capacity
SDO RO
510Fh 1 Dosierzeit für
Batch
U16 Metering time
for batch in
sec
SDO RW
5110h 1 maximale
Dosierleis‐
tung
Float Maximum
capacity
SDO RO
5112h 1 Soll-Dosier‐
leistung
Float Setpoint
metering
capacity
SDO RW
5113h 1 Auxiliarfre‐
quenz
U16 Auxiliary fre‐
quency
SDO RW
5114h 1 Auxiliar-Dos‐
ierleistung
Float Auxiliary
capacity
SDO RW
5115h 1 Dosierart U32 Metering type
(0-
optimum,1-
fast,2-sinus
mode,3-
cont.4-DFMa)
SDO RW
5117h 1 Soll-Betrieb‐
sart
U32 Setpoint
operating
mode (0-
stop,1-
manual,..)
SDO RW
5118h 1 Ist-Betrieb‐
sart
U32 Current oper‐
ating mode
SDO RO
Supplementary Operating Instructions CANopen
23

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
