Promise Technology Pegasus2 R2+ User Manual

Storage Disks
Pegasus2 R2+ supports 3.5” 6 Gbps SATA HDD for the two hard disk
drive bays.
The Media Bay accommodates one of three available types of Media Pods
for compact mobiles storage, including a 2.5” SATA HDD Pod, and an
SSD Reader Pod, both available for purchase separately. The Pegasus2
R2+isshippedwithaCF/SDReaderPodforusewithCompactFlashand
Secure Digital cards (not included).
Capacity
Total physical capacity as shipped is 6TB.
Shipment includes two 3TB 3.5” 7200 RPM hard disk drives, installed in
device.
Power supply
110W
AC input: 100-240V ~ 2.5A, 50-60Hz
AC output: 12V, 8.33A
System Fan
Dimension:92(W)x92(H)x25(D)mm/Airow:70CFM
RAID function
Hardware RAID 0 or RAID 1 (Shipped with RAID 0)
OS Support
OS X 10.8.5 or higher, Windows 7, and later versions of Windows
Hardware
monitoring
Fan, Temperature, Power, Enclosure, Physical drives, Logical drives,
RAID controller
Temperature
Operating: 5° ~ 35° C
Non-operating: -40° ~ 70° C
Humidity
Operating: 10% ~ 95% non-condensing
Storage: 5% - 95% non-condensing
Dimensions
Height : 13.48 cm (5.3 in )
Width : 18.5 cm (7.3 in)
Length : 24.95 cm (9.8 in)
Weight
As shipped with all 3.5” HDD installed: 6.1 kg (13.41 lb)
Certication
EMC: CE, FCC, VCCI, BSMI, RCM, KC
speCifiCAtions
3
Promise Technology

Promise Technology Pegasus2 R2+ Specifications
