subsysteM ProbleMs
Subsystem problem troubleshooting includes:
• “Diagnosing a Subsystem Problem”
• “Overheating”
• “Power Supply”
diAgnosing A subsysteM probleM
Check System Status on the Dashboard tab. If a yellow ! or red X appears in the System
Status box:
1. Click the name link of the component with the red X icon.
System Status box on the Dashboard, all hardware funcon normal
The list containing the problem component displays. In the case of a high- temperature issue, shown in
the example above, the Component List displays.
2. For physical drives, disk arrays, logical drives, and spare drives, mouse-over the component with
the red X icon and click the View button.
