hArdWAre
This section provides a brief introduction to the external hardware of the Pegasus2 R2+. Please note
that he appearance of the front of the enclosure will differ slightly according to the type of Media Pod
that is inserted in the Media Bay.
Pegasus2 R2+ front view
Drive Status
LED
Drive Activity LED
Portable Media
Pod in Media Bay
Hard Disk Drive
Carrier
Powerbutton/
System Status LED
USB connection LED
Thunderbolt connection LED
Pushtoeject
Media Pod
