replACing A physiCAl drive
A failed physical drive displays a red Drive Status LED on the drive carrier.
Check the failed drive, then obtain a replacement drive of the same:
• Ty p e – Hard disk drive (HDD)
• Interface – SATA 3 Gb/s or 6 Gb/s
• Spin speed – 7,200 RPM or 15,000 RPM
• Capacity – Equal size or larger
You do not have to install the identical make and model of physical drive. However replacing with the
same make and model of drive makes the process easier and simpler.
You can replace a physical drive without shutting down the Pegasus2 R2+ unit.
Activity LED is blue
Drive Status LED is red
Failed physical drive
52
Pegasus2 R2+ Product Manual
