Promise Technology Pegasus2 R2+ User Manual

dAisy-ChAining Multiple pegAsus/pegAsus2 units
Up to 6 Pegasus or Pegasus2 devices can be connected to each other and to your computer in a daisy
chain sequential Thunderbolt connection. To daisy-chain multiple Pegasus and/or Pegasus2 units:
1. Connect a Thunderbolt cable from one of the Thunderbolt ports on the back of your computer to
oneoftheThunderboltportsontherstPegasus/Pegasus2unit.
2. ConnectasecondThunderboltcablefromotherThunderboltportontherst
Pegasus/Pegasus2 unit to one of the Thunderbolt ports on the second Pegasus/Pegasus2 unit.
Thunderbolt daisy-chain connecons
iMac used for this example,
any computer with a
Thunderbolt port can be
used.
Thunderbolt port
Thunderbolt ports
(Pegasus2 M4)
Thunderbolt ports
(Pegasus2 R2+)
26
Pegasus2 R2+ Product Manual

Promise Technology Pegasus2 R2+ Specifications

General

Brand	Promise Technology
Model	Pegasus2 R2+
Category	Storage
Language	English
