troubleshooting
This chapter deals problems you might encounter with your Pegasus2 R2+ unit and how to resolve
them.
• “Checking LEDs” on page 50
• “Replacing a Physical Drive” on page 52
Pegasus2 R2+ LED indicators including 2.5” HDD pod
Drive Status LED
Drive Activity LED
Power button /
System Status LED
USB connection LED
remains dark if Thunderbolt
is connected
Thunderbolt connection LED
2.5” HDD
Status/Activity LED
49
Promise Technology
