dAshboArd

TheDashboardistherstmenudisplayedwhenyoulaunchtheutility.Thevarioussubmenusinthe

Dashboard display status information (see table below for description). Use the System Monitor pull-

down menu to change frequency of system monitor functions.

Dashboard menu Description

System Status

Provides a summary of the RAID, fan and temperature status. The color

coded icons let you know the condition of the hardware at a glance.

The green, yellow and red colored icons indicate the following

conditions:

System Monitor

Use this to change System Monitor settings or to disable it. This feature

is used to monitor the health of various components including hard disks

and the RAID. If it detects problems that might develop in the RAID,

physical drives, or other parts of the system where some predictive

analysis is possible, it will change the alert status accordingly and display

the status in the dashboard or other menus in the utility.

Note that the more frequently a system check is conducted,

Media Bay

Lists the basic information of the Media Pod, if one of the available pods

are installed. Information includes device type, storage capacity and

temperature.

HDDStorageBay

Overview

Basic status information of the hard disk drives, if present. Information

includes storage capacity and temperature.

Fan

Fan status uses the same icon indicators as System Status to display

fan health status. Basic information includes current fan speed and

operational status. If you see a red or amber icon for the fan in the

System Status menu, look here for details.

Temperature

If you see a red or amber Temperature icon under System Status, check

the details in the Temperature submenu. This displays local temperature

status of the storage bays.

The green check mark indicates healthy status.

The red ‘X’ indicates failed or critical status. If this appears,

there is a serious problem with the component.

The amber exclamation point indicates there is a problem with

the component.
