Feature Description
Thunderbolt
Ports
Use a Thunderbolt cable to connect the Pegasus2 to a Thunderbolt
ready computer. This connection completes the physical link, it is the
path through which the SATA link is established.
USB 3 Port
Use this to connect the RAID drive to computers that are not equipped
with a Thunderbolt port.
Note that the Thunderbolt connection cannot be used at the same time
as the USB 3.0 connection. One or the other can be used to connect
the RAID drive to the computer.
Cooling Vents
The cooling vents on the back should be clear and unobstructed to allow
properairowfordiskandsystemcooling.Notethattheairintakevents
located on the front of the enclosure should also be unobstructed.
Power
Receptacle
Use only the power cord shipped with the device to connect the power.
Insert one end of the power cord into the power receptacle and insert
the other end into a suitable power source such as a wall outlet or a
power strip.
Pegasus2 R2+ back view
Power Receptacle
Thunderbolt Ports
USB 3 Port
6
Pegasus2 R2+ Product Manual
