The content of each server's status data area is structured the same. The
following table describes the content of each register in the status data area:
Offset
Description
0
Number of Command Requests
1
Number of Command Responses
2
Number of Command Errors
3
Number of Requests
4
Number of Responses
5
Number of Errors Sent
6
Number of Errors Received
7
Configuration Error Word
8
Current Error Code
9
Last Error Code
MBTCP Client Status Data
The following table lists the addresses in upper memory where the PLX3x
gateway stores status data for each MBTCP Client:
Client
Address Range
0
12000 through 12025
1
12026 through 12051
2
12052 through 12077
.
.
.
.
8
12208 through 12233
9
12234 through 12259
The content of each Client’s status data area is structured the same. The
following table describes the content of each register in the status data area:
Offset
Description
0
Command Request Count (total Client commands sent)
1
Command Response Count (total command responses received)
2
Command Error Count
3
Number of Request Packets
4
Number of Response Packets
5
Errors Sent
6
Errors Received
7
Reserved
8
Current Error
9
Last Error
