PLX3x Series ♦ Multi-Protocol Gateways SIE Protocol
User Manual
ProSoft Technology, Inc. Page 157 of 215
January 25, 2018
9.2 SIE Configuration
9.2.1 Configuring SIE Client [x] Connection
Use the SIE Client [x] section in ProSoft Configuration Builder to configure the
SIE Client [x] parameters. The value of [x] depends on the number of ports on
your PLX3x gateway (1 to 4).
To configure the ASCII Port in PCB
1 In ProSoft Configuration Builder, click the [+] next to the gateway, then click
the [+] next to SIE Client [x].
2 Double-click the second SIE Client [x] to display the Edit - SIE Client [x]
dialog box.
3 In the dialog box, click a parameter and then enter a value for the parameter.
The following table defines the configuration parameters for the SIE client
(master):
Specifies the number of milliseconds to wait between the initial
issuances of a command. This parameter can be used to delay all
commands sent to servers to avoid "flooding" commands on the
network. This parameter does not affect retries of a command as
they will be issued when failure is recognized.
Specifies the time in milliseconds that a Client will wait before re-
transmitting a command if no response is received from the
addressed server. The value to use depends on the type of
communication network used, and the expected response time of
the slowest device on the network.
Specifies the number of times a command will be retried if it fails.
To Next Page
