ProSoft Technology PLX3x Series User Manual

PLX3x Series ♦ Multi-Protocol Gateways Diagnostics and Troubleshooting
User Manual
ProSoft Technology, Inc. Page 41 of 215
January 25, 2018
3.3.2 Protocol-Specific Status Data in Upper Memory
The PLX3x gateway also has upper memory locations for protocol-specific status
data. The location of the status data area for the gateway protocol drivers
depend on the protocols. For more information, see:
 EIP Status Data in Upper Memory (page 71)
 MBTCP Status Data in Upper Memory (page 108)
 MBS Status Data in Upper Memory (page 127)
 ASCII Status Data in Upper Memory (page 148)
 SIE Status Data in Upper Memory (page 171)
 PND Status Data in Upper Memory (page 205)
