ProSoft Technology PLX3x Series User Manual

PLX3x Series ♦ Multi-Protocol Gateways Hardware Information
User Manual
ProSoft Technology, Inc. Page 43 of 215
January 25, 2018
4 Hardware Information
In This Chapter
 EIP Functional Overview ....................................................................... 43
 Serial Port Cables (for Gateways with Serial Ports) .............................. 44
4.1 Hardware Specifications
Specification
Description
Power Supply
24 VDC nominal
10 VDC to 36 VDC allowed
Positive, Negative, GND Terminals
Current Load
208 mA normal @ 24 VDC normal
300 mA maximum @ 36 VDC maximum
Operating Temperature
-25°C to 70°C (-13°F to 158°F)
Storage Temperature
-40°C to 80°C (-40°F to 176°F)
Relative Humidity
5% to 95% RH with no condensation
Dimensions
(H x W x D)
5.38 x 1.99 x 4.38 in
13.67 x 5.05 x 11.13 cm
LED Indicators
(On all gateways)
 Configuration (CFG) and Error (ERR) Communication Status
 Power (PWR) and Hardware Fault (FLT)
 Network Status (NS) EtherNet/IP™ Class I or Class III Connection Status
(EtherNet/IP Only)
 Module Status (MS) Module Configuration Status (EtherNet/IP Only)
 Ethernet Communication Port Link/Activity and 100 mbit
 Serial Communication Port Receive (RX) and Transmit (TX)
Ethernet Port(s)
10/100 Mbit full-duplex RJ45 Connector Electrical Isolation 1500 Vrms at 50 Hz
to 60 Hz for 60 seconds, applied as specified in section 5.3.2 of IEC 60950:
1991
Ethernet Broadcast Storm Resiliency = less than or equal to 5000 [ARP]
frames-per-second and less than or equal to 5 minutes duration
Serial Port Isolation
2500 Vrms port signal isolation per UL 1577
serial port communication signal uses RF (Radio Frequency) modulation signal
as isolation media, IC chip model is Silicon Labs Si844x
(Si8440,Si8441,Si8442).
Shipped With Each
Unit
2.5 mm screwdriver
J180 Power Connector
(1 to 4) RJ45-DB9M Serial Adapter Cable (serial protocol only)
(1 to 4) DB9 to Screw Terminal Adapter (serial protocol only)
