ProSoft Technology PLX3x Series User Manual

PLX3x Series ♦ Multi-Protocol Gateways SIE Protocol
User Manual
ProSoft Technology, Inc. Page 167 of 215
January 25, 2018
Address Type: Input
Function
Data Type
READ
BOOL
Write
BOOL
READ
BYTE
Write
BYTE
READ
DINT
Write
DINT
READ
REAL
Write
REAL
READ
INT
Write
INT
READ
TIME
Write
TIME
READ
COUNT
Write
COUNT
Notes on Addressing in S7 Processors
This topic applies to the S7-300 and the S7-1200 processors.
The gray area represents the byte memory locations being overlapped when the
word address is used consecutively (DB1.DBW0, DB1.DBW1, DB1.DBW2, etc.).
