1.1 System Requirements
The MVI69E-MBS module requires the following minimum hardware and
software components:
 Rockwell Automation CompactLogix or MicroLogix 1500-LRP
®
processor
(firmware version 10 or higher), with compatible power supply and one free
slot in the rack, for the MVI69E-MBS module.
Important: The MVI69E-MBS module has a power supply distance rating of 4 (L43 and L45
installations on first 2 slots of 1769 bus). It consumes 500 mA at 5 VDC.
Important: For 1769-L23x processors, please make note of the following limitation:
1769-L23E-QBFC1B = 450 mA at 5 VDC (No MVI69E module can be used with this processor.)
 The module requires 500 mA of available 5 VDC power
 Rockwell Automation RSLogix 5000 programming software version 16 or
higher
 Rockwell Automation RSLinx
®
communication software version 2.51 or higher
 ProSoft Configuration Builder (PCB) (included)
 ProSoft Discovery Service (PDS) (included in PCB)
 Pentium
®
II 450 MHz minimum. Pentium III 733 MHz (or better)
recommended
 Supported operating systems:
o Microsoft Windows
®
7
o Microsoft Windows Vista
o Microsoft Windows XP Professional with Service Pack 1 or 2
o Microsoft Windows 2000 Professional with Service Pack 1, 2, or 3
o Microsoft Windows Server 2003
 128 Mbytes of RAM minimum, 256 Mbytes of RAM recommended
 100 Mbytes of free hard disk space (or more based on application
requirements)
 256-color VGA graphics adapter, 800 x 600 minimum resolution (True Color
1024 x 768 recommended)
Note: The Hardware and Operating System requirements in this list are the minimum
recommended to install and run software provided by ProSoft Technology
®
. Other third party
applications may have different minimum requirements. Refer to the documentation for any third
party applications for system requirements.
