7.4.11 Set Port and Command Active Bits Block (9500)
Block 9500: Set Port and command active bits
This block enables and disables ports, as well as individual Master commands
for a port.
Block 9500: Request from Processor to Module
Offset
Description
0
Write Block ID: 9500 to set port and command enable/disable state
1
Port 1 active state: 0=disabled, 1=enabled
2 to 21
Command enable bits for Port 1 commands (0=disabled, 1=enabled)
22
Port 2 active state: 0=disabled, 1=enabled
23 to 42
Command enable bits for Port 2 commands (0=disabled, 1=enabled)
43 to (n-1)
Spare
Where n = 60, 120, or 240 depending on the Block Transfer Size parameter.
Block 9500: Response from Module to Processor
Offset
Description
0
Read Block ID: 9500 requested by processor.
1
Write Block ID: To be used by the processor in its next Write block.
2 to (n-1)
Spare
