7.4 Function Blocks
Data contained in this database is paged through the input and output images by
coordination of the CompactLogix or MicroLogix 1500-LRP ladder logic and the
MVI69E-MBS module's program. Each block transferred from the module to the
processor or from the processor to the module contains a block identification
code that describes the content of the block.
Block ID Range
Description
-1000 to -1166
Get input image data for initialization
-1 to -999
Dummy block
0
Read or write data for small data sets
1 to 167
Read or write data
1000 to 1255
Event Command Port 1
2000 to 2255
Event Command Port 2
3000 to 3001
Port 1 slave polling control
3002 to 3006
Port 1 slave status
3100 to 3101
Port 2 slave polling control
3102 to 3106
Port 2 slave status
5001 to 5006
Port 1 Command Control
5101 to 5106
Port 2 Command Control
8000
Add Event with data for Port 1
8001
Add Event with data for Port 2
8100
Get Event with data status
9000 or -9000
Specifications of configuration file data from the processor to the module
9001 or -9001
Get configuration file from the processor to the module (continued)
9250
Get general module status data
9500
Set port and command active bits
9501
Get port and command active bits
9956
Pass-through formatted block for functions 6 and 16 with word data
9957
Pass-through formatted block for functions 6 and 16 with float data
9958
Pass-through formatted block for function 5
9959
Pass-through formatted block for function 15
9961
Pass-through formatted block for function 23
9970
Pass-through block for function 99
9972
Set module time using received time
9973
Pass module time to processor
9997
Reset status block
9998
Warm-boot control block
9999
Cold-boot control block
