MVI69E-MBS ♦ CompactLogix Platform Diagnostics and Troubleshooting
Modbus Serial Enhanced Communication Module User Manual
ProSoft Technology, Inc. Page 99 of 154
June 28, 2017
6.4.5 Monitoring Data Values in the Module’s Database
In the Diagnostics window in ProSoft Configuration Builder, click DATABASE
and then click DECIMAL to view the contents of the MVI69E-MBS module’s
internal database. You can view data values in ASCII, Hexadecimal, and Float
format.
