MVI69E-MBS ♦ CompactLogix Platform Configuring the MVI69E-MBS Using PCB
Modbus Serial Enhanced Communication Module User Manual
ProSoft Technology, Inc. Page 43 of 154
June 28, 2017
3 Configuring the MVI69E-MBS Using PCB
In This Chapter
Basic PCB Functions ............................................................................. 44
Module Configuration Parameters ......................................................... 47
Downloading the Configuration File to the Processor ............................ 56
Uploading the Configuration File from the Processor ............................ 59
ProSoft Configuration Builder (PCB) provides a quick and easy way to manage
module configuration files customized to meet your application needs.
You build and edit the module’s configuration in ProSoft Configuration Builder.
You use PCB to download the configuration file to the CompactLogix or
MicroLogix 1500-LRP processor, where it is stored in the MBS.CONFIG
controller tag generated by the previously exported AOI. See Creating and
Exporting the .L5X File (page 28). When the MVI69E-MBS module boots up, it
requests the processor to send the configuration over the backplane in special
Configuration Blocks.
See the chapter Adding the Module to RSLogix (page 17) for the procedures to
create a new PCB project and export a .L5X file for the processor. This chapter
describes the module configuration parameters in detail, as well as how to
download the configuration to the processor using PCB.
