MVI69E-MBS ♦ CompactLogix Platform Start Here
Modbus Serial Enhanced Communication Module User Manual
ProSoft Technology, Inc. Page 9 of 154
June 28, 2017
1 Start Here
In This Chapter
 System Requirements ........................................................................... 10
 Deployment Checklist ............................................................................ 10
 Package Contents ................................................................................. 11
 Setting Jumpers .................................................................................... 12
 Installing the Module in the Rack ........................................................... 13
To get the most benefit from this User Manual, you should have the following
skills:
 Rockwell Automation
®
RSLogix™ software: launch the program, configure
ladder logic, and transfer the ladder logic to the processor
 Microsoft Windows
®
: install and launch programs, execute menu
commands, navigate dialog boxes, and enter data
 Hardware installation and wiring: install the module, and safely connect
Modbus and CompactLogix or MicroLogix 1500-LRP devices to a power
source and to the MVI69E-MBS module’s application port(s)
