MVI69E-MBS ♦ CompactLogix Platform Adding the Module to RSLogix
Modbus Serial Enhanced Communication Module User Manual
ProSoft Technology, Inc. Page 29 of 154
June 28, 2017
3 Edit the Slot Number indicating where the module is placed in the 1769 bus.
4 Click OK to close the Edit – Module dialog box. The .L5X file is now ready to
be exported to the PC/Laptop.
5 Right-click the MVI69E-MBS icon in the project tree and choose EXPORT AOI
FILE.
