7.4.7 Get Event with Data Status Block (8100)
Block 8100: Get Event with Data Status
This block requests status data for Event with Data Commands.
Block 8100: Request from Processor to Module
Offset
Description
0
Write Block ID: 8100 status data request for Event with Data Commands.
1 to (n-1)
Spare
Where n = 60, 120, or 240 depending on the Block Transfer Size parameter.
Block 8100: Response from Module to Processor
Offset
Description
0
Read Block ID: 8100 status data for Event with Data Commands.
1
Write Block ID: To be used by the processor in its next Write block.
2
Event command status for Port 1:
0=No message active
1=Waiting to execute command
2=Command complete
3
Error code for last command executed for Port 1
4
Event command status for Port 2:
0=No message active
1=Waiting to execute command
2=Command complete
5
Error code for last command executed for Port 2
6 to (n-1)
Spare
