6 Diagnostics and Troubleshooting
In This Chapter
 Ethernet LED Indicators ........................................................................ 88
 LED Status Indicators ............................................................................ 88
 Connecting the PC to the Module's Ethernet Port ................................. 90
 Using the Diagnostics Menu in PCB ...................................................... 93
 Communication Error Codes ............................................................... 100
 Connecting to the Module’s Web Page ............................................... 101
The MVI69E-MBS provides information on diagnostics and troubleshooting in the
following forms:
 LED status indicators on the front of the module provide general information
on the module's status.
 You can view status data contained in the module through the Ethernet port,
using the troubleshooting and diagnostic capabilities of ProSoft Configuration
Builder (PCB).
 You can transfer status data values from the module to processor memory
and can monitor them in the processor manually or by customer-created
logic.
