In the above example, the master's Modbus command to transmit inside the
Modbus packet is as follows.
Slave Address
Function Code
Address in Device
Reg Count
DEC
01
3
6100
2
HEX
01
03
17 D4
00 02
In the above example the (Enron/Daniel supporting) slave's Modbus command to
transmit inside the Modbus packet is as follows.
Slave Address
Function Code
Byte Count
Data
DEC
01
3
8
32.75 275.69
HEX
01
03
08
00 00 42 03 D8 52 43 89
In the above example the (a NON-Enron/Daniel supporting) slave's Modbus
command that is transmitted inside the Modbus packet is as follows.
Slave Address
Function Code
Byte Count
Data
DEC
01
3
4
32.75
HEX
01
03
04
00 00 42 03
