Additional Configuration Parameters as Slave
The Type parameter must be SLAVE or PASSTHRU SLAVE to configure these
parameters. See Configuration Parameters Common to Master and Slave (page
48).
Parameter
Value
Description
Minimum
Response Delay
0 to 65535
milliseconds
Sets the number of milliseconds to wait before responding to a
command received on the port from a remote Master. This
delay is sometimes required to accommodate slower Master
devices.
Internal Slave ID
1 to 247
Defines the Slave Node Address for the internal database. All
requests received by the port with this address are processed
by the module. Verify that each device has a unique address
on a network.
Bit Input Offset
0 to 9998
Specifies the offset address into the internal Modbus database
for network requests for Modbus function 2 commands. For
example, if you set the value to 150, an address request of 0
returns the value at register 150 in the database.
Word Input Offset
0 to 9998
Specifies the offset address into the internal Modbus database
for network requests for Modbus function 4 commands. For
example, if you set the value to 150, an address request of 0
returns the value at register 150 in the database.
Output Offset
0 to 9998
Specifies the offset address into the internal Modbus database
for network requests for Modbus function 1, 5 or 15
commands. For example, if you set the value to 100, an
address request of 0 corresponds to register 100 in the
database.
Holding Register
Offset
0 to 9998
Specifies the offset address in the internal Modbus database
for network requests for Modbus function 3, 6, or 16
commands. For example, if you set the value to 50, a request
for address 0 corresponds to the register 50 in the database.
