Page 100
The third parameter has no function when control relays are chosen and will
not be displayed.
The fourth parameter and fifth parameter are set to determine the switch points,
ONand “OFF” for the relay. See control function, table (P211, 221, 231, 241,
251, 261) for further information.
P213, P223, P233, P243, P253, P263 Relay Setpoint 1
P211, 221, 231, 241, 251, 261 =1 (Time)
This parameter determines the “Time Period that the relay will remainON”.
Relay Setpoints are entered in Minutes.
See the appropriate relay Function tables (P211, 221, 231, 241, 251, 261) for further
information.
P211, 221, 231, 241, 251, 261 =2 (General)
This parameter is the “ON point for the general control relay. Relay setpoints are
entered in values of Measurement Units (P104).
P214, P224, P234, P244, P254, P264 Relay Setpoint 2
P211, 221, 231, 241, 251, 261 =1 (Time)
This parameter determines the “Cycle Time ” for the operation of the relay.
See the appropriate relay Function tables (P211, 221, 231, 241, 251, 261) for further
information.
P211, 221, 231, 241, 251, 261 =2 (General)
This parameter is the OFF” point for the general control relay. Relay setpoints are
entered in values of Measurement Units (P104).
