Page 110
Compensation Parameters
Offset
P1-P851, P2-P1851 Measurement Offset
The value of this parameter is added to the measured distance, in Measurement
Units (P104).
This Offset will be added to the level, as derived from the transducer, and will
affect everything including the reading on the display, the relay setpoints and the
mA output.
Temperature
P1-P852, P2-P1852 Temperature Source
This parameter determines the source of the temperature measurement. By default
it is set to automatic (P852/P1852=1), which will automatically detect if a
temperature sensor is available from the transducer. If for any reason, no
temperature input is received, then the Fixed Temp value is used, as set by
P854/P1854.
The temperature source can be specifically set as follows:
Will automatically select transducer
temperature sensor, if available, or fixed
temperature (P854/P1854) if no
temperature sensor found.
P1-P854, P2-P1854 Fixed Temperature
This parameter sets the temperature, in degrees Celsius, to be used if P852/P1852
(Temperature Source) =3. Default = 20
o
C
