Page 28
Transceiver Mounting
The Sludge Finder 2 transceiver is mounted in an IP65 rated enclosure.
These enclosures are often situated out in the open on the walkways or bridges of
settlement tanks and are therefore very exposed to the elements.
With this in mind we offer a metal enclosure similar to the one below to ensure that, if
required, the unit is not mounted in direct sunlight and is sheltered from any potential
exposure to water ingress via precipitation or the application itself.
A steel enclosure with optional mounting plate and
brackets is recommended as a suitable enclosure.
Dimensions: W x H x D: 400 mm x 400 mm x 200 mm
are adequate.
Requirements: General protection of electrical and
other equipment against impact and the ingress of dust
and liquids.
Example Spec
• Overall sheet steel construction.
• Epoxy powder coated to RAL7032.
• Earth points on enclosure body & door.
• IP55 protection as standard.
• Polyurethane gasket.
Note: Enclosure mounting equipment supplied and fitted by others to suit local site
conditions.
