Page 102
Common Parameters
P216, P226, P236, P246, P256, P266 - Relay Allocation
This parameter determines which input the relay will act on. You can set it to the
transducer1 (default), transducer 2 or an average, sum or differential of the two
when available.
Option
Description
1 = Xducer 1 (Default)
Relay acts on Xducer 1calculated levels.
2 = Xducer 2
Relay acts on Xducer 2 calculated levels.
3 = Average of 1 & 2
Relay acts on the resulting average levels of
two signal inputs.
4 = Sum of 1 & 2
Relay acts on the resulting sum level of two
signal inputs
5 = Differential of 1 & 2
Relay acts on the resulting differential level
of two signal inputs.
P217, P227, P 237, P247, P257, P267 - Relay Closures
The Sludge Finder 2 will record how many times each relay is closed, this
parameter displays the number of times the relay has activated since the relay has
been in use. It can be reset with any value.
P218, P228, P238, P248, P258, P268 - Relay Fail Safe
Your Sludge Finder 2 has a general fail-safe parameter P808. However, this can
be overridden so that each individual relay has its own independent fail safe mode.
This parameter determines what the relay will do in the event of the Fail safe Time
(P809) expiring.
Option
Description
0 = Default
Relay assumes system default mode P808
1 = Hold
Relay remains in its current state
2 = De-Energise
Relay will De-Energise
3 = Energise
Relay will Energise
