Page 5
Product Specification
Physical
Wall Mount
Outside dimensions 235 x 184 x 120 mm
Weight Nominal 1 kg
Enclosure material/description Polycarbonate, flame resistant to UL94-5V
Cable entry detail 10 cable entry knock outs, 5 x M20
and 1 x M16 underside,
4 x PG11 at rear
Transducer cable extensions 2 twisted pair 0.5mm
2
with overall screen
Maximum separation 200 m
Environmental
IP Rating (Wall) IP65
Max. & min. temperature (electronics) -20 ºC to +50 ºC
Flammable atmosphere approval Safe area: compatible with approved dB
transducers (see transducer spec' sheet)
CE Approval See EC Declaration of Conformity
Performance (with Sludge)
Accuracy 0.25% of the measured range or
10 mm (whichever is greater)
Resolution 0.25% of the measured range or 10 mm
(whichever is greater)
Max. range 10m
Min. range 0.3m
Outputs
Analogue output 2 off Isolated (to 150V floating) output of 4-
20 mA or 0-20 mA into 1k
(user
programmable and adjustable) 0.1%
resolution
Digital output Half Duplex RS232
Volt free contacts, number and rating 6 form "C" (SPDT) rated at 5A at 115V AC
Display 192 x 128 pixel illuminated graphical display
Fully programmable display options Integral
keypad with menu navigation keys
Radio Modem (optional) 4 – 20mA using wireless exempt
frequencies
Maximum range 500m line of site
Communication bus (optional) RS485 Modbus RTU/ASCII or Profibus
DPV0 or DPV1 (slave device)
Programming
On-board programming By integral keypad
PC programming via RS232
Programming security Via passcode (user selectable and
adjustable)
