Pulsar SLUDGE FINDER 2 User Manual

Page 54
Information screen
The information screen can be used to view system details such as Software
revision, serial number etc. but can also be used to view a summary of the
application settings. To access the information screen, press the button when
the Sludge Finder 2 is in run mode. There are 4 pages within the information
screen, preceded by the pulsar logo, showing the current page number at the
bottom centre of the information screen. The screens will automatically scroll but
can also use the left and right arrow keys to toggle between pages an example of
page 1 is shown below:
Page 1: General information on the system, see example above.
Page 2: Information on communications set up incl. RS232 and RS485 (if
available).
Page 3: Information on application set up incl. transducer type, mode, empty level
etc.
Page 4: Information on mA output set up incl. mode, allocation etc.
Sub menu
heading
Parameter list
Current value
Units (none
in this case)
