Pulsar SLUDGE FINDER 2 User Manual

Page 107
mA Output Parameters
mA Out 1 / mA Out 2
P1-P830, P2-P890 mA Range
This parameter determines the range of the mA output, from the following.
Option
Description
0= Off
mA output disabled.
1= 0 to 20 mA
mA output directly proportional to the mA mode
(P831/P891), so if the reading is 0% the output is 0 mA.
If the reading is 100% the output is 20 mA.
2= 4 to 20 mA
(Default)
mA output directly proportional to the mA mode
(P831/P891), so if the reading is 0% the output is 4 mA.
If the reading is 100% the output is 20 mA.
3= 20 to 0 mA
mA output inversely proportional to the mA mode
(P831/P891), so if the reading is 0% the output is 20 mA.
If the reading is 100% the output is 0 mA.
4= 20 to 4 mA
mA output inversely proportional to the mA mode
(P831/P891), so if the reading is 0% the output is 20 mA.
If the reading is 100% the output is 4 mA.
P1-P831, P2-P891 mA Mode
This parameter determines how the mA Output relates to what is measured. By
default it operates exactly the same as the display (mode of operation
P100/P1100), but it can be set to operate as follows:
Option
Description
0 = Default
mA output relative to Mode P100
1 = Distance
mA output relative to distance.
2 = Level
mA output relative to level.
3 = Space
mA output is relative to space.
4* = Average Level
mA output is relative to average level.
5* = Differential
mA output is relative to differential level.
* If transducer 2 is enabled
