Pulsar SLUDGE FINDER 2 User Manual

Page 15
Transducer 2
VT Transducer
Terminal Connection Details
Unit Type
Orange
Motor
Red
Power
White
Signal
Black
0 volts
Green
Screen
Terminal no.
41
42
43
44
44
dB Transducer
Terminal Connection Details
Unit Type
N/C
Red
Power
White
Signal
Black
0 volts
Green
Screen
Terminal no.
41
42
43
44
44
Relay Outputs
The six relays can be programmed for a variety of alarms or process control
functions. The relay contacts are all rated at 5A at 115V AC. All connections
should be such that the short circuit capacity of the circuits to which they are
connected, is limited by fuses rated such that they do not exceed the relay rating.
Current Outputs
These are isolated (floating) active mA outputs (to 150 V), of 4 - 20mA or 0 -
20mA, and the load should not exceed 1k

.
RS232 Serial Interface
If required, you can connect to the serial interface, to operate your Sludge Finder
2 remotely.
