Specifications (continued)
Common Features
Ground Continuity: Test Current: 100 mA DC +/- 10%
Range: 10mΩ to 10Ω, in 1mΩ steps
Accuracy: +/- (5% of reading + 20mΩ)
Limits: Programmable Hi/Lo during Test Time
(Lo can be set to Off : Hipot & GC, Hi can be set to Off for IR)
Programmable Hi/Lo during Ramp Time (AC/DC Hipot only)
(Both limits can be set to Off)
Ground Fault Shutdown within 2msec for current imbalance > 250µA (AC)
Interrupt: > 400µA (DC)
Arc Detection: Arc Level AC: 0.5mA - 15mA in 0.5mA increments
Arc Level DC: 0.5mA - 15mA in 0.5mA increments
Arc Time: 1 to 50 µsec programmable
Indication: Pass/fail display, lights, audible sound
Buzzer Level: Low, High, Off
Time: AC Hipot: Ramp, Test, Fall: 0.1 to 999sec (+/-50ms)
DC Hipot: Ramp, Dwell, Test, Fall: 0.1 to 999sec (+/-50ms)
IR: Ramp, Dwell, Test, Fall: 0.1 to 999sec (+/-50ms)
GC: Test: 0.1 to 999sec (+/-55ms)
(Test can be set to Continuous. Ramp, Dwell, & Fall can be set to Off)
Standard Interfaces: RS-232
Remote:
Inputs: Start, Stop
Characteristics: TTL active low, Pulse width >1ms
Outputs: Pass, Fail, Under Test
Characteristics: Dry contact relay, Closed if true
36V, 100mA max
Connector: 9 pin male D-series (compatible w/Sentry Series)
Test Setups: 25 User Defined (shipped with some factory settings)
9 Multi-step (3 steps)
Connectors: Front and Rear Connection
High Voltage: Locking, Amp Part # 861610-2
Return: BNC female (Selectable for ground or virtual ground)
Continuity: Standard Banana Socket
Front Panel Lockout: 6 Digit Password with or without setup recall
Miscellaneous: Continue Step on Fail Stop Test on Pass
Continuous Voltage on Fail Step and Increment
