Introduction Page 31 of 31
Table 1-1
Front Panel Controls and Indicators
Fig 1-1
Ref. # Item Function
1 Power Rocker style switch which supplies power to the tester (with OFF (0) and
ON (1) markings).
2 FAIL Measured results indicate a fail condition based on set limits.
Indicator
3 PASS Measured results indicate a pass condition based on set limits.
Indicator
4 STOP Pressing this button halts a test or tests in process and shuts down the high
BUTTON voltage.
5 START Pressing this button starts a test or tests. All other keys, except STOP, are
BUTTON inactive until the test is complete. START is also used to initiate the Zero
Offset function or Calibration.
6 Display Readout to the operator of programmed tests and test results.
7 TEST Pressing this key will sequentially scroll through test setups (in ascending
order) based on how the Utilities Menu is configured (shows all tests or
only those enabled).
Test number is shown in upper left display as, user defined (1 - 25), or
sequence tests (S1 - S9). On sequence tests (S1 - S9) the first test in the
sequence will be displayed.
8 PROGRAM Pressing this key will allow the user to program the parameters of the test
KEY number presently displayed (Program appears in upper right display). In
Program mode UP/DOWN arrow changes the test parameter conditions.
RIGHT arrow selects the next parameter and exits program mode (back to
Idle) after the last parameter is displayed. LEFT arrow selects the
previous parameter.
Pressing PROGRAM key at any time exits the programming mode back
to Idle.
To program another test, from the Idle mode, press TEST key to select
desired test number and press PROGRAM key.
To Next Page
