Introduction Page 33 of 33
Table 1-1 (continued)
Front Panel Controls and Indicators
Fig 1-1
Ref. # Item Function
13 REMOTE When illuminated indicates that the instrument has been enabled for
Indicator remote operation. (Illuminates green on late model instruments)
GFI ACTIVE When illuminated (green) indicates that the instrument has been enabled
Indicator for Ground Fault Stop. (Indicator not present on some earlier units)
14 HIGH When indicator is flashing (or constantly lit on some later units) serves as
VOLTAGE a warning to the operator that high voltage is present to the High Voltage
Indicator Output connector.
15 GROUND Continuity test connection, measured between this connector and the
CONTINUITY Return (accepts the small white clip lead cable with banana plug)
Connector Standard banana plug.
16 RETURN Ground return for High voltage output (accepts the black clip lead cable
Connector with BNC connector). Selectable for ground or virtual ground.
BNC female
17 HIGH High voltage output for AC/DC hipot & insulation
VOLTAGE resistance measurements, jack recessed for safety purposes (accepts the
Connector large white clip lead cable with high voltage connector).
Amp Part # 861610-2
