QuadTech Guardian 2500 Series User Manual

Page 80 of 80 Interface
Table 3-4: IEEE & RS-232 Commands
Command Function Parameter(s)
TEST:
TEST Set the test number nn
STEP Set the step number n
SEQuence Set the sequence test number n
CONFigure:
MODe Set measurement mode NONE AC ACRE
ACIM DC IR
GCOnly
VOLT Set the voltage in KV n.nnn
HIGh Set High limit in mA for Hipot test nn.nnn
mΩ for GC test
kΩ for IR test (2530)
LOW Set Low limit in mA nn.nnn OFF
mΩ for GC test
kΩ for IR test (2530)
ARC Set the ARC limit in mA nn.nnn OFF
TRAmp Set the Ramp time in seconds nnn.n OFF
RHIGh Set Ramp High limit in mA nn.nnn OFF
RLOW Set Ramp Low limit in mA nn.nnn OFF
TDWell Set the Dwell time in seconds nnn.n OFF
TMEasure Set the Test Measurement time in seconds nnn.n TCONtinuous
TFAll Set the Fall time in seconds nnn.n OFF
FREQuency Set the frequency to either 50 or 60 Hz 50 60
GNDCont Set Ground Continuity limit in ohms nn.nn OFF
Valid Parameters for Mode Selected
AC Total
AC Real
AC Imag
DC
IR
GC
VOLT
X
X
X
HIGh
X
X
X
X
LOW
X
X
X
X
ARC
X
X
TRAmp
X
X
X
RHIGh
X
X
X
RLOW
X
X
X
TDWell
X
X
TMEasure
X
X
X
X
TFAll
X
X
X
FREQuency
X
X
GNDCont
X
X
X
