17.1.2. Database of labels
While in Counting pieces mode press F key on the balance keyboard or F2 on
PC keyboard.
After pressing arrow to the right list of defined labels will open. Choice of label
can be done by arrows up and down, however enter to edition arrow to the right
- fig.20.
Fig.20. Database of labels
1 – number of label
2 – name of label
name Name of label (28 signs)
index 4 digits
Id
6 signs. This name must be the same as name of label design
saved in printer memory. Label design is made in “LABELS”
software attached to CITIZEN CLP printer equipment.
fields Submenu to choose variables to place on printout (on label)
C39/E128
Submenu to choose variables, which are to be introduced as
bar code in code39/ EAN128 format
After choice of submenu “fields” (arrow to the right) following screen will open
fig.21.
Fig.21. Choice of variable to print
