EB200 Manual SYSTem subsystem
4052.2000.02 4.102 E-7
. :AUDio:REMote:MODe <numeric_value>
Sets the mode of the digital AF that is transferred via the remote control interface per UDP. See also
Appendix F.
Parameter:
<numeric_value> Mode 0 to 13 of digital AF
Mode Sampling rate
[kHz]
Bits pro sample Channels Data rate
[kbyte/s]
Length per frame
[bytes]
0 - - - 0
1 32 16 2 128 1
2 32 16 1 64 2
3 32 8 2 64 2
4 32 8 1 32 1
5 16 16 2 64 4
6 16 16 1 32 2
7 16 8 2 32 2
8 16 8 1 16 1
9 8 16 2 32 4
10 8 16 1 16 2
11 8 8 2 16 2
12 8 8 1 8 1
13 GSM 6.10 - 1 1.625 65
GSM 6.10 is a standard for the compression of AF data
*RST status:
0
Example:
SYSTem:AUDio:REMote:MODe 5
. :AUDio:REMote:MODe?
Query of the set digital AF mode.
Parameter:
None
Example:
SYSTem:AUDio:REMote:MODe? -> 5
