R&S EB200 - Preselection, Frontend, if Section, IF-Panorama (Option)

EB200 Manual Maintenance and Troubleshooting
4052.2000.02 5.12 E-7
5.2.4.6 Preselection, frontend, IF section, IF-panorama (option)
2
3
1
3
Screw out the screws
(4 pieces) and pull out
the modules with their
housing.
2
Screw out screws
at bottom
(2 pieces).
1
Carefully pull off the
plug of the antenna
line.
